ICON Vehicle Dynamics 2019-2023 Ford Ranger suspension systems are designed to dramatically increase the on and off-road ride quality. ICON engineers’ primary focus is to increase wheel travel and damping ability, which translates into outstanding vehicle control and ride quality both on and off-road. With wheel travel and ride quality in mind, ICON engineers researched each component of the new Ranger platform’s suspension and addressed any areas where performance could be extracted. The Stage 1 system includes vehicle-specific tuned 2.5 Series coilover shocks featuring an internal reservoir for exceptional cooling properties and ICON-engineered coil springs for superior vehicle “feel” through the range of travel. These coilovers are also height adjustable from 0-3.5” allowing the use of larger, more aggressive wheel and tire combinations. ICON 2.0 Aluminum Series monotube rear shocks utilize a vehicle-specific valving that balances the performance of the truck from front to rear. The ICON Vehicle Dynamics 2019-2023 Ford Ranger Stage 1 suspension system is an excellent choice for those drivers looking to enhance the capabilities of their pickup on the road as well as in the dirt.
Specifications:
- Lift height: 0-3.5"
- Position: Front and Rear
Installation notes:
- Recommended Aftermarket Wheel Size: 17x8.5" with 5.75” Backspace / 25mm Offset
- Up to 33x11.25" Tire with Minor Fender Trimming
- with 1.5" Maximum Lift Rear
Fits:
- 2019-2020 Ford Ranger: Lariat, XLT (Front and Rear) — Raises Front 0" - 3.5"
- 2021-2023 Ford Ranger: Lariat, XLT (Front and Rear) — with Tremor Package; Raises Front 0" - 2.5"
- 2021-2023 Ford Ranger: Lariat, XLT (Front and Rear) — without Tremor Package; Raises Front 0" - 3.5"
- 2019-2023 Ford Ranger: XL (Front and Rear) — Raises Front 0" - 3.5"
- 2021-2022 Ford Ranger: XLT Plus (Front and Rear) — Raises Front 0" - 3.5"
Part #: K93201
