BDS Suspension 4 Inch Lift Kit Ram 1500 2013-2018 4WD
-
Free shipping on orders over $100
-
Secure payments
- Available
BDS steps up the performance and capability of the 2013-2018 RAM 1500 trucks with a 4-inch suspension lift kit. Designed to improve stance, performance, and capability, this kit includes everything necessary to set your truck up right with clearance for up to 35 inch Tires
This kit takes advantage of BDS's tried and true high-clearance design for improved ground clearance, strength, and offroad protection while correcting suspension and steering geometry for great on-road handling characteristics.
Up front, the kit utilizes top mounted strut spacers, high-arched 1/4-inch thick steel crossmembers along with a multipiece differential relocation brackets and heavy duty skid plates built for offroad protection.
Steering geometry is corrected at the new taller ride height with CNC-machined ductile iron steering knuckles and replacement tie rod ends allowing for ESC system compatibility.
These combined with the provided sway bar drops, bump stop extensions, stainless steel braided brake lines, CV spacers, supplied hardware and more provide a comprehensive front suspension lift ready for whatever you throw at it.
In the rear this kit utilizes a 2 inch coil spacer, rear upper control arm relocation brackets to correct pinion angle, track bar relocation bracket to correct axle positioning, bump stop extensions, and sway bar links.
The rear of these kits are rounded out with your choice of specially tuned NX2 nitro series gas shocks or FOX 2.0 Internal Floating Piston performance series gas shocks to offer improved damper performance.
High Clearance Crossmembers
BDS maximizes ground clearance with their heavy duty 1/4-inch thick laser cut perfect fit crossmembers. Paired with a front skid plate system that bolts together to create a rigid subframe while adding extra protection.
Heavy Duty Steering Knuckles
BDS corrects steering geometry at the new taller ride height using a pair of high-strength, CNC machined ductile cast iron steering knuckle design to work with replacement tie rod ends to maintain steering angles for proper function and ESC compatibility.
Rear Lift Option 3 Inch Coil Springs
These vehicles vary from 1 inch to 3 inch tail high from the factory. BDS offers 3 inch rear coil springs (standard) or 2 inch rear coil spring spacers. Measure your vehicle and order the appropriate rear lift height to get your desired stance.
Coil Springs
FOX 2.0 Performance Series
Features:
Fitment Notes (from BDS):
Specifications:
Options & Part Numbers:
| Option | Part # | Shocks Included | What's in the Box |
|---|---|---|---|
| 3 Inch Coil Springs / FOX 2.0 Performance Series | BDS1754FS | Yes | one BDS022309, 09-18 Dodge 1500 3in Rear Box Kit one BDS022402, 2012 Dodge 1500 4in Frnt Box Kit 3of4 one BDS022625, 2012 Dodge 1500 6 in Frnt Box Kit 4 of 4 one BDS022630, 2013 DODGE 1500 4WD FRONTBOXKIT (1 OF 4) one BDS022631, 2013 DODGE 4WD FRONTBOXKIT (2 OF 4) two FOX98224758, Fox 2.0 Shock 27.95 x 17.35 x 2- EB1/EB1 |
| 3 Inch Coil Springs / NX2 Nitro Series | BDS1754H | Yes | one BDS022309, 09-18 Dodge 1500 3in Rear Box Kit one BDS022402, 2012 Dodge 1500 4in Frnt Box Kit 3of4 one BDS022625, 2012 Dodge 1500 6 in Frnt Box Kit 4 of 4 one BDS022630, 2013 DODGE 1500 4WD FRONTBOXKIT (1 OF 4) one BDS022631, 2013 DODGE 4WD FRONTBOXKIT (2 OF 4) two BDS85758, Shock- 27.90 x 16.55 x 2-3/8 - EB1/EB1 |
| 2 Inch Coil Spacer / FOX 2.0 Performance Series | BDS670FS | Yes | one BDS022209, 09-12 Dodge 1500 2 Inch Rear Spacer Kit one BDS022402, 2012 Dodge 1500 4in Frnt Box Kit 3of4 one BDS022625, 2012 Dodge 1500 6 in Frnt Box Kit 4 of 4 one BDS022630, 2013 DODGE 1500 4WD FRONTBOXKIT (1 OF 4) one BDS022631, 2013 DODGE 4WD FRONTBOXKIT (2 OF 4) two FOX98224758, Fox 2.0 Shock 27.95 x 17.35 x 2- EB1/EB1 |
| 2 Inch Coil Spacer / NX2 Nitro Series | BDS670H | Yes | one BDS022209, 09-12 Dodge 1500 2 Inch Rear Spacer Kit one BDS022402, 2012 Dodge 1500 4in Frnt Box Kit 3of4 one BDS022625, 2012 Dodge 1500 6 in Frnt Box Kit 4 of 4 one BDS022630, 2013 DODGE 1500 4WD FRONTBOXKIT (1 OF 4) one BDS022631, 2013 DODGE 4WD FRONTBOXKIT (2 OF 4) two BDS85758, Shock- 27.90 x 16.55 x 2-3/8 - EB1/EB1 |
Fits:
Part #: BDS1754FS, BDS1754H, BDS670FS, BDS670H
